Produce larger sessions with Universal Audio's most powerful desktop Apollo. Featuring the highest-resolution audio conversion, four Unison™ mic preamps, and real-time UAD processing — letting you record through plug-ins from Neve, API, Manley, Auto-Tune, and hundreds more — Apollo x4 levels up your studio with legendary UA sound, built to inspire your next collaboration.
Essentials Plug-ins Bundles:
- Channel Strips & Preamps: Century Tube Channel Strip, CS-1 Channel Strip, Helios Type 69 Preamp & EQ, Precision Channel Strip, UA 610-A Preamp & EQ, UA 610-B Preamp & EQ
- Compressors/Limiters: Fairchild 670 Legacy, Teletronix LA-2A Classic Leveler, Teletronix LA-2A Gray Classic Leveler, Teletronix LA-2A Silver Classic Leveler, Teletronix LA-2A Legacy Leveling Amplifier, UA 1176LN Legacy, UA 1176SE Legacy
- Equalizers: Helios Type 69 Legacy EQ, Pultec EQP-1A Legacy EQ, Pultec EQP-1A Passive EQ, Pultec HLF-3C Passive EQ, Pultec MEQ-5 Passive EQ, Pultec Pro Legacy EQ
- Special Processing: Auto-Tune Realtime Access, Oxide Tape Recorder, Precision Enhancer Hz, Verve Analog Machines Essentials
- Instruments: PolyMAX Polyphonic Synth
- Delay & Modulation: Galaxy Tape Echo, Precision Delay Mod, Precision Delay Mod L
- Reverbs & Rooms: Precision Reflection Engine, Pure Plate Reverb, RealVerb Pro Custom Room Modeler
- Guitar & Bass: Ampeg SVT-VR Classic Bass Amplifier, Marshall Plexi Classic Amplifier, Raw Distortion
Features:
- 12 x 18 Thunderbolt 3 audio interface with QUAD Core DSP plug-in processing
- Four Unison™ mic preamps, two Hi-Z instrument inputs, optical Toslink I/O (ADAT or S/PDIF)
- Two 1/4" monitor outs, four 1/4" line outs (ALT 1 / 2), two 1/4" TRS headphone outs
- Elite-class Apollo X Gen 2 converters with 24-bit / 192 kHz resolution
- Enhanced D/A for critical monitoring and playback with 129 dB dynamic range
- Fully-featured monitor controller with alternate speaker switching and integrated talkback for easy communication with talent
- Updated UAD Console app featuring Auto-Gain, Plug-In Scenes, subwoofer integration with Bass Management, immersive audio support, and more
- Onboard DSP supports over 200 UAD plug-ins via VST, AU, and AAX 64 formats in all major DAWs
- Includes up to 50 UAD plug-ins with Essentials or Studio Editions
- Compatible with LUNA, Logic Pro, Pro Tools, Cubase, Ableton Live, and more
- Expandable with Thunderbolt Apollo interfaces or select models over Dante
- Free industry-leading technical support from knowledgeable audio engineers
Specifications:
- Simultaneous Channel I/O Count (analog digital): 12 x 18 (ADAT mode)
- Microphone Inputs: Four (XLR female, pin 2 positive -combo XLR/TRS), 20 Hz – 20 kHz, ±0.05 dB Frequency Response, 10 dB to 65 dB Gain Range, 48V Phantom Power (switchable per mic input)
- High Impedance (Hi-Z) Instrument Inputs: Two ¼" female TS unbalanced, 20 Hz – 20 kHz, ±0.05 dB Frequency Response, 10 dB to 65 dB Gain Range
- Analog Line Inputs: Four ¼" female TRS balanced, 20 Hz – 20 kHz, ±0.05 dB Frequency Response, 10 dB to 65 dB Gain Range
- Analog Line Outputs (DC coupled): Four (six including Monitor outputs) ¼" female TRS balanced, 20 Hz – 20 kHz, ±0.05 dB Frequency Response
- Analog Monitor Outputs (DC coupled): Two (one stereo pair) ¼" female TRS balanced, 20 Hz – 20 kHz, ±0.04 dB Frequency Response
- Headphone Outputs: Two ¼" female TRS stereo, 20 Hz – 20 kHz, ±0.01 dB
- Digital Audio Port (ADAT or S/PDIF, selectable): One input, one output (Optical TOSLINK JIS F05 connector)
- S/PDIF Channels: One stereo input, one stereo output
- ADAT Channels: Up to eight input & eight output channels
- Internal, ADAT, S/PDIF: Conditional per selected digital input type
- Thunderbolt 3 Port: One (Mac Only)
- Simultaneous A/D Conversion: Four channels
- Simultaneous D/A Conversion: 10 channels
- Supported Sample Rates (kHz): 44.1, 48, 88.2, 96, 176.4, 192
- Bit Depth Per Sample: 24
- Analog Round-Trip Latency: 1.1 milliseconds @ 96 kHz sample rate
- Power Supply External AC-to-DC power supply, level VI compliant
- Includes: Apollo x4 Gen 2 audio interface, External power supply and region-specific AC cable, (USA, EU, UK, ANZ, or Japan), Getting Started URL card
- Dimensions: 9.17" (W) x 5.87" (D) x 2.51" (H) / 232.98 mm (W) x 149.13 mm (D) x 65.81 mm (H)
- Weight: 1.47 kg / 3.2 lbs
